Quick Facts
- Compatible with CURT channels #48610 and #48650
- Secured by a dual-bolt mounting system
- Channel-mount allows for easy height adjustment
- Solid neck for increased strength and greater corrosion resistance
- Sleeve-lock latch system with included safety pin for optimum security
- Safety pin hole can also accept a coupler lock
- Constructed from heavy-duty cast steel
- Protected by a durable gloss black powder coat finish
- Limited lifetime warranty (one-year finish, one-year parts)
Specifications
- SKU: 2020103034
- Brand: Curt™
- Product Color: Black
- Coupler Type: Channel-Mount
- Gross Trailer Weight (GTW): 12,500 lbs.
- Tongue Weight Capacity: 1,875 lbs.
- Ball Diameter: 2-5/16"
- Country of Origin: CHN
- Quantity In Package: 1
- Warranty Term: Limited lifetime warranty (one-year finish, one-year parts)
- Unit of Measure: EA
- Item Length (Inches): 4.400
- Item Width (Inches): 5.500
- Item Height (Inches): 10.750
- Item Weight (Pounds): 12.340
- Universal Part: Yes
- Manufacturer Reference Number: 25329
- UPC: 612314253296

CURT 2-5/16" Channel-Mount Coupler with Sleeve-Lock (12,500 lbs, Black) #25329

Name: CURT 2-5/16" Channel-Mount Coupler with Sleeve-Lock (12,500 lbs, Black) #25329
SKU: 2020103034
Price: 112.95 USD
Availability: InStock

SKU #: 2020103034

Free Shipping! US and Canada only

Universal Vehicle Fit

This CURT channel-mount coupler uses a pair of bolts to mount onto an adjustable eye channel to allow for easy height adjustment. It features a sleeve-lock latch and a solid neck for increased strength and security.

More details

Quantity:

In Stock

Usually Ships Same or Next Business Day

Select Product Options for estimated delivery

Quick Facts
- Compatible with CURT channels #48610 and #48650
- Secured by a dual-bolt mounting system
- Channel-mount allows for easy height adjustment
- Solid neck for increased strength and greater corrosion resistance
- Sleeve-lock latch system with included safety pin for optimum security
- Safety pin hole can also accept a coupler lock
- Constructed from heavy-duty cast steel
- Protected by a durable gloss black powder coat finish
- Limited lifetime warranty (one-year finish, one-year parts)
Specifications
- SKU: 2020103034
- Brand: Curt™
- Product Color: Black
- Coupler Type: Channel-Mount
- Gross Trailer Weight (GTW): 12,500 lbs.
- Tongue Weight Capacity: 1,875 lbs.
- Ball Diameter: 2-5/16"
- Country of Origin: CHN
- Quantity In Package: 1
- Warranty Term: Limited lifetime warranty (one-year finish, one-year parts)
- Unit of Measure: EA
- Item Length (Inches): 4.400
- Item Width (Inches): 5.500
- Item Height (Inches): 10.750
- Item Weight (Pounds): 12.340
- Universal Part: Yes
- Manufacturer Reference Number: 25329
- UPC: 612314253296

Product description

Support

Product description

If you are replacing a broken coupler on your trailer or installing a new one on a trailer you are building, CURT has dependable couplers you can trust to keep your tow load latched on tight. Selecting the right trailer hitch, ball mount and trailer ball to manage the weight of your trailer is not the only important aspect of towing; you also need a trailer that can stand up to the road ahead. That means equipping it with a coupler that is built to go the distance. Providing the highest weight capacity and the most flexibility in coupler design, CURT adjustable channel couplers are a unique option for your trailer. This type of coupler does not bolt onto a trailer's frame the same way that a standard coupler does. It uses a pair of bolts to mount onto an adjustable eye channel to allow for easy height adjustment. The two attachment bolts also provide greater stability and less rattle. This CURT adjustable channel coupler features a sleeve-lock latch and a solid neck for increased strength and security. It comes with a durable gloss black powder coat finish for corrosion resistance and has a gross trailer weight capacity of 12,000 lbs. and a tongue weight capacity of 1,875 lbs. It is designed to fit a 2-5/16" diameter trailer ball. All CURT couplers include a limited lifetime warranty and feature a lockable latch to give you peace of mind.

FEATURES:

EASILY ADJUSTABLE. Designed to mount onto a vertical channel bracket, this trailer hitch coupler can easily be adjusted up or down to ensure level towing across your vehicle and trailer (CURT channels #48610 and #48650 recommended, sold separately)
SECURE COUPLING. The sleeve-lock latch mechanism of this trailer tongue coupler fully encompasses the trailer ball when coupled, providing maximum security and safety for towing
PRECISE FIT. This trailer coupler can be mounted on a wide variety of heavy-duty trailers and couple to any standard 2-5/16-inch diameter trailer ball
HIGH-STRENGTH. Constructed from heavy-duty cast steel, this trailer ball coupler has a capacity of 12,500 lbs. gross trailer weight and 1,875 lbs. tongue weight
CORROSION-RESISTANT. To easily outlast the elements, including rain, snow, dirt, road grime and more, this adjustable trailer coupler is finished in a durable black powder coat
